    GBT 18674-2018 4-Strand Mixed Polypropylene And Polyethylene Fishery Ropes

    Ask Lasest Price
    Brand Name : YONGDA
    Model Number : 4-strand Mixed Polypropylene and Polyethylene Fishery Ropes
    Certification : Class certificates (RINA, BV, CCS, KR, NK, ABS, DNV, LR, IRS, RS, EC, TUV and Mill Certificate)
    Price : As per quotation
    Payment Terms : T/T, L/C, etc.
    Supply Ability : As ordered
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    GBT 18674-2018 4-Strand Mixed Polypropylene And Polyethylene Fishery Ropes

    GB/T 18674-2018 4-strand Mixed Polypropylene and Polyethylene Fishery Rope

    Description:

    GBT 18674-2018 4-strand Mixed Polypropylene and Polyethylene Fishery Ropes has strong, lightweight, abrasion resistant, thermally bondable and comfortable property. It is also has property of resistant to sunlight, soil and staining. Mixed polypropylene and polyethylene is resistant to deterioration from chemicals, perspiration, mildew, rot and weather. It also has quick drying properties and able to provide a good bulk and cover. It is made up of bi-component fibres made of a blend during extrusion of polypropylene and of polyethylene , with a minimum of 15 % and a maximum of 50 % of polyethylene. GBT 18674-2018 4-strand Mixed Polypropylene and Polyethylene Fishery Ropes can be widely used in Krill trawl net, Marine ranch super - large wind and wave cage.


    Main Technical Specifications:

    1.Standard: GB/T 18674-2018

    2.Material: Polypropylene and of polyethylene

    3.Diameter: 6mm to 72mm

    4.Construction: 4-strand hawser-laid

    5.Type: Knit

    6.Test: Destructive and Tension test

    7.Classification Certificates: RINA ,BV ,CCS ,CR ,NK ,ABS ,DNV ,LR and Mill Certificate

    8.Color: White, green,yellow or as your needs

    9.Application: Krill trawl net, Marine ranch super - large wind and wave cage

    10.Advantages: lightweight, abrasion resistant, thermally bondable and comfortable, resistant to sunlight, soil and staining, resistant to deterioration from chemicals, perspiration, mildew, rot and weather


    Main Technical Parameters:

    Linear density and minimum breaking force of

    GBT 18674-2018 4-strand Mixed Polypropylene and Polyethylene Fishery Ropes

    Reference NO.
    mm
    Linear densityMinimum breaking strength kN
    Nominal
    ktex
    Tolerance
    %
    Superior ProductTop Qualified ProductQualified Product
    616.3±106.085.785.46
    829.010.59.989.45
    1045.3±816.215.414.6
    1265.222.921.819.5
    1488.830.629.126.0
    16116±539.237.233.3
    1814749.146.641.7
    2018159.656.650.6
    2221971.267.660.5
    2426183.579.371.0
    2630696.391.581.8
    2835511110594.4
    30408126120107
    32464141134120
    36587175166148
    40725211200179
    44877249236211
    481040293278249
    521220338321287
    561420386368328
    601630437415371
    641860490465416
    682100548520466
    722350609578518

    1.The reference number corresponds to the approximate diameter, in millimetres.

    2.The linear density, in kilotex, corresponds to the net mass per length of the rope, expressed in grams per metre or in kilograms per kilometre.

    3. The breaking forces relate to new, dry ropes.

    4.When the rope fracture position including splice eye,the minimum breaking strength should be reduced 10%.

    5. A force determined by the test methods specified in GB/T 8834 is not necessarily an accurate indication of the force at which that rope might break in other circumstances and situations. The type and quality of terminations, the rate of force application, prior conditioning and previous force applications to the rope can significantly influence the breaking force. A rope bent around a post, capstan, pulley or sheave may break at a significantly lower force. A knot or other distortion in a rope may significantly reduce the breaking force.


    Drawing of GBT 18674-2018 4-strand Mixed Polypropylene and Polyethylene Fishery Ropes:

    Product Photo of GBT 18674-2018 4-strand Mixed Polypropylene and Polyethylene Fishery Ropes:
